Application
※ Direct replacement of traditional R7S bulb lamp
※ Ideal application for medical, landscape and architecture lighting
※ Widely used for restaurant, hotel, meeting room, showcase, showroom, cabinet and other place decoration etc.
Technical Parameter
※ Product Dimension: Ø20.5mm X 78mm (L); Ø20.5mm X 118mm (L); Ø20.5mm X 135mm (L); Ø20.5mm X 189mm (L).
※ Working Voltage: AC85~265V
|
Part No.
|
Emitting Color (CCT)
|
Wattage(W)
|
LED Qty
|
Luminous Flux (lm)
|
|
R7S-42CS-5W-CW
|
Cool White (5000K-7000K)
|
5.0±10%
|
42
|
520
|
|
R7S--42CS-5W-NW
|
Neutral White (3500-5000K)
|
5.0±10%
|
42
|
520
|
|
R7S-42CS-5W-WW
|
Warm White (2700K-3500K)
|
5.0±10%
|
42
|
500
|
|
R7S-70CS-8W-CW
|
Cool White (5000K-7000K)
|
8.0±10%
|
70
|
800
|
|
R7S-70CS-8W-NW
|
Neutral White (3500-5000K)
|
8.0±10%
|
70
|
800
|
|
R7S-70CS-8W-WW
|
Warm White (2700K-3500K)
|
8.0±10%
|
70
|
770
|
|
R7S-105CS-12W-CW
|
Cool White (5000K-7000K)
|
12.0±10%
|
105
|
1200
|
|
R7S--105CS-12W-NW
|
Neutral White (3500-5000K)
|
12.0±10%
|
105
|
1200
|
|
R7S-105CS-12W-WW
|
Warm White (2700K-3500K)
|
12.0±10%
|
105
|
1100
|
|
R7S-168CS-15W-CW
|
Cool White (5000K-7000K)
|
15.0±10%
|
168
|
1500
|
|
R7S-168CS-15W-NW
|
Neutral White (3500-5000K)
|
15.0±10%
|
168
|
1500
|
|
R7S-168CS-15W-WW
|
Warm White (2700K-3500K)
|
15.0±10%
|
168
|
1400
|
